Plan Details
Square Footage Breakdown
Total Heated Area: 1772 sq. ft.
1st Floor:1772 sq. ft.
Front Patio: 160 sq. ft
Back Patio:728 sq. ft.
Beds/Baths
Bedrooms:3
Full Bathrooms:2
Foundation Type
Standard Foundations: Slab/ Sonotubes
Exterior Walls
Standard Type(s):Shipping Container
Plan includes the following elements:
Cover Sheet
Foundation Plan
Floor Plan(s)
Elevations (x2)
Roof Plan
Framing Plan(s)
Roof Framing Plan
Details/Sections
Electrical Plan(s)
These items are NOT included:
Architectural or Engineering Stamp - handled locally if required
Site Plan - handled locally when required
Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
Energy calculations - handled locally when required
Dimensions
Width:52’0”
Depth:54’0”
Ceiling Heights
Main/ 9' 0"
Roof Details
Primary Pitch: 1:12
